| CPU |
AMD Socket sTR5, supports AMD Ryzen™ Threadripper™ PRO 7000 processors and AMD Ryzen™ Threadripper™ 7000 Series processors. |
| Chipset |
AMD TRX50 |
| Memory |
| DDR5 ECC Registered memory (RDIMM/RDIMM-3DS), 8 x DIMM sockets, up to 2 TB. |
| – 8-Channel memory with AMD Ryzen™ Threadripper™ PRO 7000 Processors. |
| – Quad-Channel memory with AMD Ryzen™ Threadripper™ 7000 Processors. |
| Supports AMD EXPO™ and XMP profiles. |
|
| Audio |
Realtek® ALC4080 (rear panel): DTS:X® Ultra, HD Audio, 2-channel. Realtek® ALC897 (front panel). |
| LAN |
2 x Marvell® AQtion AQC113C 10GbE LAN chips. |
| Wireless |
Qualcomm® Wi-Fi 7 QCNCM865 (802.11a/b/g/n/ac/ax/be), Bluetooth 5.3. |
| Expansion Slots |
3 x PCIe x16 (5.0) slots for CPU, 1 x PCIe x16 (4.0 or 5.0). |
| Storage Interface |
| 3 x PCIe 5.0/4.0 M.2 connectors, 1 x PCIe 5.0/4.0 M.2 connector, 4 x SATA 6Gb/s connectors. |
| RAID 0, 1, 10 for NVMe SSD; RAID 0, 1 for SATA devices. |
|
| USB |
| – CPU: 4 x USB 3.2 Gen 2 Type-A ports. |
| – Chipset+Intel® USB4®: 2 x USB4® Type-C® ports. |
| – Chipset: USB 3.2 Gen 2×2 and USB 3.2 Gen 1/2 ports. |
|
| Internal I/O |
24-pin ATX, 2 x 8-pin ATX 12V, 4 x PCIe power, 4 x M.2, 4 x SATA, RGB headers, fan headers, noise detection. |
| Back Panel |
Q-Flash Plus button, SMA antenna connectors, DisplayPort, USB4® ports, RJ-45, audio jacks. |
| H/W Monitoring |
Voltage, temperature, fan speed, water flow rate detection, noise detection. |
| BIOS |
256 Mbit AMI UEFI BIOS, Q-Flash, Q-Flash Plus, Smart Backup. |
| Unique Features |
GIGABYTE Control Center (GCC), support for Windows 11 64-bit and Ubuntu 24.04 LTS. |
| Form Factor |
E-ATX; 30.5 cm x 33.0 cm. |
