GIGABYTE Z790 UD AC WIFI DDR5

179 JOD

Description
Specification

Supported Processors	LGA1700 socket: Support for the 13th and 12th Generation Intel® Core™ Pentium® Gold and Celeron® Processors
Chipset	Intel® Z790 Express Chipset
Socket	LGA1700
Memory Type	DDR5
Memory Slots	4
Maximum Memory	192GB
Memory Bus Speed	Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 memory modules4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memoryDual channel memory architectureSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modules
Ports	1 x USB Type-C® port with USB 3.2 Gen 2×2 support1 x USB 3.2 Gen 2 Type-A port (red)4 x USB 3.2 Gen 1 ports4 x USB 2.0/1.1 ports2 x SMA antenna connectors (1T1R)1 x HDMI 2.0 port1 x DisplayPort1 x RJ-45 port3 x audio jacks
Form Factor	ATX
M.2 Slots	Yes
Expansion Slots	CPU:1 x PCI Express x16 slot supporting PCIe 5.0 and running at x16 (PCIEX16)* For optimum performance if only one PCI Express graphics card is to be installed be sure to install it in the PCIEX16 slot.Chipset:1 x PCI Express x16 slot supporting PCIe 4.0 and running at x4 (PCIEX4)2 x PCI Express x16 slots supporting PCIe 3.0 and running at x1 (PCIEX1_1 PCIEX1_4)2 x PCI Express x1 slots supporting PCIe 3.0 and running at x1 (PCIEX1_2 PCIEX1_3)Support for AMD CrossFire™ technology (PCIEX16 and PCIEX4)

Categories: Components, Intel, Intel-DDR5, MotherBoard Tags: cpu, electronics, game, gaming, gpu, motherboard, performa, performapc, store

Description
Specification

Brands	Gigabyte
CPU Socket	Intel Socket
Intel Socket	LGA 1700
Motherboard Form Factor	Full ATX
Motherboard Manufacturer	Intel
Motherboard Socket - intel	LGA 1700
RAM Generation	DDR5
