Phanteks PH-TC12DX Black U-Type dual tower heat-sink with dual PWM 120mm fans

P.A.T.S (Physical Antioxidant Thermal Shield) will greatly increase the cooling performance and reliability while deflecting other thermal radiation from other heat sources, such as the GPU, South Bridge, North Bridge, etc. P.A.T.S, ran at a long period, will display significantly better results in an enclosure, closed environment, than a tech station, open environment. In extreme conditions, PATS is able to withstand temperatures of up to 200 degrees Celsius. P.A.T.S is environmental friendly and non-toxic.

C.P.S.C (Cold Plasma Spraying Coating Technology) is a brand new technologic forming deposit that displaces heat onto corresponding metals at a quicker rate. With this technology, the Phanteks PH-TC12DX enhances thermal conductivity on the soldered surfaces of the heat-pipes through the copper deposits.

Phanteks PH-F120HP PWM Premium fans uses UFB (Updraft Floating Balance) bearing, Nine blades and MAFO (Maelstrom Air-Fort Optimization) drive system to achieve massive airflow and perfect dynamic balance. The PH-F120HP fans with the support of the anti-acoustic rubber pad and rubber bar produces low level dB(A) and eliminates vibration. With PWM functions built in, PH-F120HP fans allows you to set speed adjustments for either performance and/or silent operation.

Phanteks PH-NDC is made of high purity Nano diamond-like particles to improve the thermal conductance between components. The PH-NDC is a superb quality thermal compound for heat-sinks. Heat generated by CPUs will transfer to the heat-sinks without reduction in efficiency and resistance.

Fan Size: 120mm

Compatibility: Intel LGA 1150/2011/1150/1155/1156/1366/775
AMD FM2/FM1/AM3+/AM3/AM2+/AM2 (Stock back-plate required)

RPM: 600 – 1800 RPM +/-10%

Airflow: 23 – 68.5 CFM

Noise Level: 21.9 – 27.6 dBA

Power Connector: 4 pins

Available Colors: Black & White

Material: Aluminum & Copper

Dimensions & Weight:

Fan Dimension: 120 x 120 x 25mm

Weight: 606g (without fans)
880g (with fans
